Шипованные колеса

Изображения могут отличаться от продукта. Подробнее см. технические характеристики.

Стандарт

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Материал

440C Stainless steel/Polymer (overmold) 440C

Вес

6g-403g

Монтажный шестигранник (H)

19mm-22mm

Бренд

QIBR/OEM/Neutral/BWC

Упаковка

QIBR/Standard Industrial Package/OEM

Применения

Electronics, medical, laboratory

Шипованные колеса

Filters

NO. Product Product Number Наружный диаметр (D) Вес Ширина (B) Монтажный шестигранник (H) Номинальная осевая нагрузка Номинальная радиальная нагрузка
1 SWIC0P/ SWIC0P 14.83 mm 6 g 6.35 mm 11 mm 6 lbf 3 lbf
2 SWSC0A/ SWSC0A 14.83 mm 9 g 6.35 mm 9.53 mm 146 lbf 28 lbf
3 SWSC0XA/ SWSC0XA 14.83 mm 9 g 6.35 mm 9.53 mm 146 lbf 28 lbf
4 SWSC0SS227A/ SWSC0SS227A 14.83 mm 9 g 6.35 mm 9.53 mm 121 lbf 23 lbf
5 SWIE0P/ SWIE0P 14.83 mm 6 g 6.35 mm 11 mm 6 lbf 3 lbf
6 SWSE0A/ SWSE0A 14.83 mm 9 g 6.35 mm 9.53 mm 146 lbf 28 lbf
7 SWSE0XA/ SWSE0XA 14.83 mm 9 g 6.35 mm 9.53 mm 146 lbf 28 lbf
8 SWSE0SS227A/ SWSE0SS227A 14.83 mm 9 g 6.35 mm 9.53 mm 121 lbf 23 lbf
9 SWAC0/ SWAC0 14.83 mm 9 g 6.35 mm 11 mm
10 SWAC0X/ SWAC0X 14.83 mm 9 g 6.35 mm 11 mm
11 SWAC0SS227/ SWAC0SS227 14.83 mm 9 g 6.35 mm 11 mm
12 SWAE0/ SWAE0 14.83 mm 9 g 6.35 mm 11 mm
13 SWAE0X/ SWAE0X 14.83 mm 9 g 6.35 mm 11 mm
14 SWAE0SS227/ SWAE0SS227 14.83 mm 9 g 6.35 mm 11 mm
15 SWIC1P/ SWIC1P 19.58 mm 11 g 7.87 mm 12 mm 12 lbf 6 lbf
16 SWSC1A/ SWSC1A 19.58 mm 17 g 7.87 mm 11.11 mm 274 lbf 57 lbf
17 SWSC1XA/ SWSC1XA 19.58 mm 17 g 7.87 mm 11.11 mm 274 lbf 57 lbf
18 SWSC1SSXA/ SWSC1SSXA 19.58 mm 17 g 7.87 mm 11.11 mm 274 lbf 57 lbf
19 SWSC1SS227A/ SWSC1SS227A 19.58 mm 17 g 7.87 mm 11.11 mm 228 lbf 47 lbf
20 SWSC1SS300A/ SWSC1SS300A 19.58 mm 17 g 7.87 mm 11.11 mm 228 lbf 47 lbf
21 SWIE1P/ SWIE1P 19.58 mm 11 g 7.87 mm 12 mm 12 lbf 6 lbf
22 SWSE1A/ SWSE1A 19.58 mm 17 g 7.87 mm 11.11 mm 274 lbf 57 lbf
23 SWSE1XA/ SWSE1XA 19.58 mm 17 g 7.87 mm 11.11 mm 274 lbf 57 lbf
24 SWSE1SSXA/ SWSE1SSXA 19.58 mm 17 g 7.87 mm 11.11 mm 274 lbf 57 lbf
25 SWSE1SS227A/ SWSE1SS227A 19.58 mm 17 g 7.87 mm 11.11 mm 228 lbf 47 lbf
26 SWSE1SS300A/ SWSE1SS300A 19.58 mm 17 g 7.87 mm 11.11 mm 228 lbf 47 lbf
27 SWAC1/ SWAC1 19.58 mm 20 g 7.87 mm 12 mm
28 SWAC1X/ SWAC1X 19.58 mm 20 g 7.87 mm 12 mm
29 SWAC1SSX/ SWAC1SSX 19.58 mm 20 g 7.87 mm 12 mm
30 SWAC1SS227/ SWAC1SS227 19.58 mm 20 g 7.87 mm 12 mm
31 SWAC1SS300/ SWAC1SS300 19.58 mm 20 g 7.87 mm 12 mm
32 SWAE1/ SWAE1 19.58 mm 20 g 7.87 mm 12 mm
33 SWAE1X/ SWAE1X 19.58 mm 20 g 7.87 mm 12 mm
34 SWAE1SSX/ SWAE1SSX 19.58 mm 20 g 7.87 mm 12 mm
35 SWAE1SS227/ SWAE1SS227 19.58 mm 20 g 7.87 mm 12 mm
36 SWAE1SS300/ SWAE1SS300 19.58 mm 20 g 7.87 mm 12 mm
37 SWIC2P/ SWIC2P 30.73 mm 27 g 11.13 mm 14 mm 16 lbf 9 lbf
38 SWSC2XA/ SWSC2XA 30.73 mm 56 g 11.13 mm 14.29 mm 596 lbf 141 lbf
39 SWSC2SSXA/ SWSC2SSXA 30.73 mm 56 g 11.13 mm 14.29 mm 596 lbf 141 lbf
40 SWSC2SS227A/ SWSC2SS227A 30.73 mm 56 g 11.13 mm 14.29 mm 494 lbf 117 lbf
41 SWSC2SS300A/ SWSC2SS300A 30.73 mm 56 g 11.13 mm 14.29 mm 494 lbf 117 lbf
42 SWSCWD2SSXA/ SWSCWD2SSXA 30.73 mm 56 g 11.13 mm 14.29 mm 544 lbf 90 lbf
43 SWIE2P/ SWIE2P 30.73 mm 27 g 11.13 mm 14 mm 16 lbf 9 lbf
44 SWSE2XA/ SWSE2XA 30.73 mm 56 g 11.13 mm 14.29 mm 596 lbf 141 lbf
45 SWSE2SSXA/ SWSE2SSXA 30.73 mm 56 g 11.13 mm 14.29 mm 596 lbf 141 lbf
46 SWSE2SS227A/ SWSE2SS227A 30.73 mm 56 g 11.13 mm 14.29 mm 494 lbf 117 lbf
47 SWSE2SS300A/ SWSE2SS300A 30.73 mm 56 g 11.13 mm 14.29 mm 494 lbf 117 lbf
48 SWSEWD2SSXA/ SWSEWD2SSXA 30.73 mm 56 g 11.13 mm 14.29 mm 544 lbf 90 lbf
49 SWAC2X/ SWAC2X 30.73 mm 75 g 11.13 mm 14 mm
50 SWAC2SSX/ SWAC2SSX 30.73 mm 75 g 11.13 mm 14 mm
51 SWAC2SS227/ SWAC2SS227 30.73 mm 75 g 11.13 mm 14 mm
52 SWAC2SS300/ SWAC2SS300 30.73 mm 75 g 11.13 mm 14 mm
53 SWACWD2SSX/ SWACWD2SSX 30.73 mm 75 g 11.13 mm 14 mm
54 SWAE2X/ SWAE2X 30.73 mm 75 g 11.13 mm 14 mm
55 SWAE2SSX/ SWAE2SSX 30.73 mm 75 g 11.13 mm 14 mm
56 SWAE2SS227/ SWAE2SS227 30.73 mm 75 g 11.13 mm 14 mm
57 SWAE2SS300/ SWAE2SS300 30.73 mm 75 g 11.13 mm 14 mm
58 SWAEWD2SSX/ SWAEWD2SSX 30.73 mm 75 g 11.13 mm 14 mm
59 SWSC3XA/ SWSC3XA 45.8 mm 166 g 15.88 mm 19.05 mm 1326 lbf 382 lbf
60 SWSC3SSXA/ SWSC3SSXA 45.8 mm 166 g 15.88 mm 19.05 mm 1326 lbf 382 lbf
61 SWSC3SS227A/ SWSC3SS227A 45.8 mm 166 g 15.88 mm 19.05 mm 1101 lbf 317 lbf
62 SWSC3SS300A/ SWSC3SS300A 45.8 mm 166 g 15.88 mm 19.05 mm 1101 lbf 317 lbf
63 SWSCWD3SSXA/ SWSCWD3SSXA 45.8 mm 166 g 15.88 mm 19.05 mm 1169 lbf 130 lbf
64 SWSE3XA/ SWSE3XA 45.8 mm 166 g 15.88 mm 19.05 mm 1326 lbf 382 lbf
65 SWSE3SSXA/ SWSE3SSXA 45.8 mm 166 g 15.88 mm 19.05 mm 1326 lbf 382 lbf
66 SWSE3SS227A/ SWSE3SS227A 45.8 mm 166 g 15.88 mm 19.05 mm 1101 lbf 317 lbf
67 SWSE3SS300A/ SWSE3SS300A 45.8 mm 166 g 15.88 mm 19.05 mm 1101 lbf 317 lbf
68 SWSEWD3SSXA/ SWSEWD3SSXA 45.8 mm 166 g 15.88 mm 19.05 mm 1169 lbf 130 lbf
69 SWAC3X/ SWAC3X 45.8 mm 193 g 15.88 mm 19 mm
70 SWAC3SSX/ SWAC3SSX 45.8 mm 193 g 15.88 mm 19 mm
71 SWAC3SS227/ SWAC3SS227 45.8 mm 193 g 15.88 mm 19 mm
72 SWAC3SS300/ SWAC3SS300 45.8 mm 193 g 15.88 mm 19 mm
73 SWACWD3SSX/ SWACWD3SSX 45.8 mm 193 g 15.88 mm 19 mm
74 SWAE3X/ SWAE3X 45.8 mm 193 g 15.88 mm 19 mm
75 SWAE3SSX/ SWAE3SSX 45.8 mm 193 g 15.88 mm 19 mm
76 SWAE3SS227/ SWAE3SS227 45.8 mm 193 g 15.88 mm 19 mm
77 SWAE3SS300/ SWAE3SS300 45.8 mm 193 g 15.88 mm 19 mm
78 SWAEWD3SSX/ SWAEWD3SSX 45.8 mm 193 g 15.88 mm 19 mm
79 SWSC4XA/ SWSC4XA 59.94 mm 338 g 19.05 mm 22.23 mm 2181 lbf 900 lbf
80 SWSC4SSXA/ SWSC4SSXA 59.94 mm 338 g 19.05 mm 22.23 mm 2181 lbf 900 lbf
81 SWSC4SS227A/ SWSC4SS227A 59.94 mm 338 g 19.05 mm 22.23 mm 1810 lbf 747 lbf
82 SWSC4SS300A/ SWSC4SS300A 59.94 mm 338 g 19.05 mm 22.23 mm 1810 lbf 747 lbf
83 SWSE4XA/ SWSE4XA 59.94 mm 338 g 19.05 mm 22.23 mm 2181 lbf 900 lbf
84 SWSE4SSXA/ SWSE4SSXA 59.94 mm 338 g 19.05 mm 22.23 mm 2181 lbf 900 lbf
85 SWSE4SS227A/ SWSE4SS227A 59.94 mm 338 g 19.05 mm 22.23 mm 1810 lbf 747 lbf
86 SWSE4SS300A/ SWSE4SS300A 59.94 mm 338 g 19.05 mm 22.23 mm 1810 lbf 747 lbf
87 SWAC4X/ SWAC4X 59.94 mm 403 g 19.05 mm 22 mm
88 SWAC4SSX/ SWAC4SSX 59.94 mm 403 g 19.05 mm 22 mm
89 SWAC4SS227/ SWAC4SS227 59.94 mm 403 g 19.05 mm 22 mm
90 SWAC4SS300/ SWAC4SS300 59.94 mm 403 g 19.05 mm 22 mm
91 SWAE4X/ SWAE4X 59.94 mm 403 g 19.05 mm 22 mm
92 SWAE4SSX/ SWAE4SSX 59.94 mm 403 g 19.05 mm 22 mm
93 SWAE4SS227/ SWAE4SS227 59.94 mm 403 g 19.05 mm 22 mm
94 SWAE4SS300/ SWAE4SS300 59.94 mm 403 g 19.05 mm 22 mm
